TALOS M50
Automatic bollard for perimeter security
Automatic oil-hydraulic system, 230 Va
Designed for the highest levels of perimeter security, this fully retractable oil-hydraulic bollard is ideal for embassies, military bases, government buildings, financial institutions, and other high-risk sites. Crash tested to withstand a 16,500 lb vehicle travelling at 50 mph while remaining fully operational, it provides exceptional hostile vehicle mitigation and reliable access control. An optional Emergency Fast Operation (EFO) version is available for rapid deployment in critical situations.
The advanced oil-hydraulic system features automatic locking in the raised position, emergency manual lowering, and a tamper-resistant release mechanism. A dual lobe pump drive unit, optional heating for temperatures down to -40°F, integrated LED lighting, Hall effect sensors, movement warning beeper, and an intelligent control unit ensure dependable operation and precise control of single or multiple bollards.
Manufactured from scratch-resistant, cataphoresis-treated steel with a durable polyester powder-coated finish, the bollard is built for maximum durability. An optional AISI 304 stainless steel sleeve, IP66-rated electrical connections, protective rubber top edge, and an impressive 2,000,000 J breakout resistance ensure outstanding performance. Certified to ASTM F2656-15 C750, PAS 68:2013, and IWA 14-1:2013 standards, it delivers trusted protection for the world's most security-sensitive sites.
Applications
Product Features
Benefits
-
Airports
-
Government Buildings
-
Critical Infrastructure
-
Commercial Developments
-
Traffic Control Systems
-
High-Security Perimeter Protection
-
Restricted Access Areas
-
Sensitive Facilities
-
Fully Retractable Oil-Hydraulic Security Bollard
-
Hydraulic Lock in Raised Position
-
Manual Emergency Lowering
-
Tamper-Resistant Release System
-
Scratch-Resistant Steel Rising Cylinder
-
Cataphoresis Treatment & Polyester Powder-Coated Finish
-
Optional AISI 304 Stainless Steel Sleeve
-
Hall Effect Limit Switch Sensors
-
Integrated LED Lighting
-
Protective Rubber Top Edge
-
IP66-Rated Connectors & Junction Box
-
Movement Warning Beeper
-
Optional Heating System for Temperatures Down to -40°F (-40°C)
-
Electronic Control Unit
-
Multi-Bollard Control Capability
-
Breakout Resistance: 700,000 J
-
Designed in Accordance with ASTM F2656-07, PAS 68:2013 & IWA 14-1 Specifications
-
Reliable High-Security Vehicle Access Control
-
Enhanced Perimeter Protection for Sensitive Sites
-
High Resistance to Forced Vehicle Attack
-
Corrosion-Resistant Construction for Long Service Life
-
Built for Intensive Daily Operation
-
Secure Hydraulic Locking System
-
Safe Emergency Manual Operation
-
Reliable Performance in Harsh Weather Conditions
-
Dependable Operation in Temperatures Down to -40°F (-40°C)
-
Flexible Control with Advanced Safety Accessories
-
Precise Coordination of Single or Multiple Bollards
-
Long Service Life with Low Maintenance
-
Easy Integration into High-Security Installations
TALOS M50
Automatic bollard for perimeter security
Automatic oil-hydraulic system, 230 Va
Cylinder diameter (inches)
Cylinder thickness (inches)
Cylinder height from ground (inches)
Cylinder material: S355K2H Steel
Cylinder treatment and finishing: cataphoresis and polyester powder coating RAL 7016AISI 304 brushed SS steel sleev
Pit: hot dip galvanization
Rising time (s) [cm/s] ~5,00 [20]
Lowering time (s) [cm/s] ~3,20 [31]
Working temperature (°F) -4 / 176 -40 [A]
Oil type: 187 gallons
Power supply (Vac – Hz) 230 - 50
Absorbed power (W) 3.100 (1.550 + 1.550)
Absorbed current (A) 10 / 13
Grade of protection IP / motor-pump: 67
Frequency of use (cycles/day): heavy duty / 2,000
Impact resistance (J) 700,000
Breakout resistance (J) 2,000,000
Maximum static load (kg) 44
